Histioteuthis cerasina: Photophore Pictures

Richard E. Young and Michael Vecchione
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Figure. Ventral-oblique view of H. cerasina, Hawaiian waters. Photograph by R. young.

Photographs below are of a preserved squid and show the basic photophore groups, from different views, with superimposed lines and dots to emphasize the photophore groups. Photographs below left are the same pictures without superimposed lines and dots so that the photophores can be seen without obstruction. The superimposed lines are formed by first placing white dots over the pigmented, photogenic cups of all photophore in a particular group. The dots are then joined by a line of the appropriate color.

The color coding of the lines is as follows:
  • Midline Series
  • Ventral Matrix
  • longitudinal series (thin blue lines)
  • Basal Arm IV Row
  • Right Eyelid Series
  • Left Eyelid Series
  • 2° Right Eyelid Series
  • 2° Left Eyelid Series
  • Basal row
  • Right basal series
  • Left basal series
  • Right Accessory Series
  • Left Accessory Series
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window

Figure. Various views of the head of H. cerasina, 60 mm ML, Hawaiian waters, preserved. Photographs by R. Young.



Figure. Lateral view of the photophores of the right eyelid in a living H. cerasina. Photograph by R. Young.
