Carinaria lamarcki Péron and Lesueur 1810

Roger R. Seapy
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Containing group: Carinaria

Introduction

This is the second largest species (to 220 mm body length) among the six species of Carinaria. The proboscis is short and the trunk moderately long. Both the proboscis and trunk have a thick cutis, the thickness of which increases with age. The tail lacks the thick cutis of the proboscis and trunk. The dorsal crest of the tail is low. The shell is broadly triangular in side view, with the height about one-half the basal length. The keel is moderately low, and increases gradually in height with proximity to the shell aperture.

Brief Diagnosis

A species of Carinaria with:



Characteristics

  1. Body
    1. Maximal body length 220 mm (Tesch, 1949; from the Mediterranean Sea). In contrast, the largest specimen among the 45 collected by midwater trawls from the middle North Atlantic Ocean (Pafort-van Iersel, 1983) was only 115 mm.
    2. Proboscis short and trunk moderately long, with both body regions having a thick cutis (see title illustration) that increases in thickness with age (Richter and Seapy, 1999)
    3. Tail lacks the thick cutis of the proboscis and trunk and has a low dorsal crest (see title illustration)
    4. Eye shape triangular in dorsal view (click on title illustration for enlarged view of eye)
    5. Left tentacle long; right one greatly reduced (click on title illustration for enlarged view of left tentacle)

  2. Shell
    1. Shell broadly triangular in side view (see first photograph below); shell height about one-half the basal length (comparable with C. challengeri)
    2. Keel moderately well developed; height increases gradually with proximity to shell aperture (see first photograph below)
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Stalked visceral nucleus and gills, covered by the transparent shell, in Carinaria lamarcki, viewed from right side of body. ©

    3. Shell apex in adult shells with ventrally-directed protoconch (see first photograph below)
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Apical portion of shell in Carinaria lamarcki, from right side (left) and close up of protoconch (right). ©

    4. Shell spire with two equally-spaced and elevated spiral ridges on the second whorl; the outer ridge ends about one-quarter whorl before the inner one (for an enlarged view, click on the third larval shell SEM below)

  3. Radula (first SEM below) with central, rachidian teeth (second SEM below) bearing three elongate and pointed median cusps. The median cusps are of unequal length; the middle one is slightly longer than the other two
    Click on an image to view larger version & data in a new window
    Click on an image to view larger version & data in a new window

    Figure. Scanning electron micrographs of the radula of Carinaria lamarcki at low (left) and high (right) magnifications. Scale bars = 200 µm (left) and 20 µm (right). Photographs from Richter and Seapy (1999). © G. Richter

  4. Larvae
    1. Velum comprised of six velar arms; each arm is bordered by a thin line of brown pigment and has a small, terminal brown patch (Thiriot-Quiévreux, 1975)
    2. Body with brown mantle, digestive tube and opercular lobe; digestive gland yellow (Thiriot-Quiévreux, 1975)
    3. Larval shell transparent and globular, with an oval aperture and a low, conical spire (see first SEM below). Shell spire (see third SEM below) with two equally-spaced and elevated spiral ridges on the second whorl
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window
      Click on an image to view larger version & data in a new window

      Figure. Scanning electron micrographs of the larval shell of Carinaria lamarcki; apertural view (left), shell tilted about 30° from apertural view (middle), and close up of the spire (right). Photographs from Thiriot-Quiévreux (1975; Fig. 1E-G). © 1975 C. Thiriot

Comments

Only a single study (Pafort-van Iersel, 1983) has been conducted on the diel vertical distribution of Carinaria lamarcki. During the mid North Atlantic Plankton Expedition, paired 1-m2 and 8-m2 opening-closing midwater trawl nets were towed at depth intervals of 50-100 m, at 100 m intervals between 100 and 500 m, and at 500-1,000 m. A total of 45 specimens were collected, which the author regarded as low in comparison with the species' common occurrence in the Mediterranean and Caribbean Seas. Based on this observation, she speculated that C. lamarcki is a neritic species and disperses into the open ocean from the above-mentioned adjacent seas. A noteworthy finding was that no specimens were captured by the 1-m2 net; all were recorded from the 8-m2 net. This result can be explained either as the result of C. lamarcki occurring in such low numbers that the smaller net captured no individuals or, more plausibly, that the species is able to avoid capture by the smaller net. Among the day and night tows from the depth intervals below 200 m sixteen individuals were collected during the day and only one at night (from 300-400 m). In the upper 200 m only one individual was collected during the day (from 100-200 m), while seven were recorded at night (five from 50-100 m and two from 100-200 m). Taken together, these results support an hypothesis of nocturnal vertical migration from mesopelagic into epipelagic waters.

References

Pafort-van Iersel, T. 1983. Distribution and variation of Carinariidae and Pterotracheidae (Heteropoda, Gastropoda) of the Amsterdam Mid North Atlantic Plankton Expedition 1980. Beaufortia 33: 73-96.

Richter, G. and R. R. Seapy. 1999. Heteropoda, pp. 621-647. In: D. Boltovskoy (ed.), South Atlantic Zooplankton. Backhuys Publishers, Leiden.

Seapy, R. R. and C. Thiriot-Quiévreux. 1994. Veliger larvae of Carinariidae (Mollusca: Heteropoda) from Hawaiian waters. Veliger 37: 336-343.

Thiriot-Quiévreux, C. 1975. Observations sur les larves et les adultes de Carinariidae (Mollusca: Heteropoda) de l'Océan Atlantique Nord. Marine Biology 32: 379-388.

Title Illustrations
Click on an image to view larger version & data in a new window
Click on an image to view larger version & data in a new window
Scientific Name Carinaria lamarcki
Location Florida Current
Specimen Condition Live Specimen
Identified By Ronald Gilmer
Sex Female
Life Cycle Stage adult
View right side
Copyright © Ronald Gilmer
